Product Features:

Kohler tubs are fully covered under warranty for up to a year after installation
Tub is constructed of ExoCrylic - offers a lighter, more manageable installation
Soaking tub - provides the user with a soothing and relaxing bathing experience
The Archer Series takes its design from traditional Craftsman furniture
Comfort Height design - provides a lower wall to step over when entering the bath, but maintains the comfortable soaking depth of standard tubs
Installs in a drop in configuration
Tub comes standard with molded lumbar support and armrests, furthering the user's comfort
Textured bottom surface.
Equipped with an overflow assembly, permitting the user to enjoy a deep soak without worrying about spillage
ADA compliant - complies with the standards set forth by the Americans with Disabilities Act

Product Technologies / Benefits:

- Material - ExoCrylic: Kohler baths constructed of ExoCrylic material are 30% lighter than standard tubs, produce 90% fewer volatile organic compounds (VOCs) during manufacturing, and offer an easier, mortarless installation.

Product Specifications:

Overall Height: 19" (measured from rim to bottom of tub)
Overall Width: 32" (measured from back outer rim to front outer rim)
Overall Length: 66" (measured from left outer rim to right outer rim)
Basin Width (Bottom): 19-5/8" (back to front measurement at bottom of basin walls)
Basin Length (Bottom): 50-3/8" (right to left measurement at top of basin walls)
Basin Width (Top): 24-1/16" (back to front measurement at top of basin walls)
Basin Length (Top): 57-5/16" (right to left measurement at top of basin walls)
Water Depth: 15-5/16" (depth of water at tub's maximum capacity)
Maximum Water Capacity: 66 gallons
Drain Location: Reversible
Drop-In Cutout Required: 64-1/2" x 30-1/2"

Variations of K-1948:

K-1948-W1: soaking bath and bask heated surface version of this tub
K-1949-G: bubblemassage air bath version of this tub
K-1949-GW: bubblemassage air bath and bask heated surface version of this tub
K-1949-VB: vibracoustic version of this tub
K-1949-VBW: vibracoustic and bask heated surface version of this tub
K-1949: whirlpool version of this tub
K-1949-H: whirlpool and heater version of this tub
K-1949-W1: whirlpool and bask heated surface version of this tub
K-1949-XHG: whirlpool and bubblemassage air bath version of this tub
