Product Features:

• Kohler tubs are fully covered under warranty for up to a year after installation
• Tub is constructed of ExoCrylic - offers a lighter, more manageable installation
• Soaking tub - provides the user with a soothing and relaxing bathing experience
• The Archer Series takes its design from traditional Craftsman furniture
• Comfort Height design - provides a lower wall to step over when entering the bath, but maintains the comfortable soaking depth of standard tubs
• Installs in a three-wall alcove configuration
• Tub comes standard with molded lumbar support and armrests, furthering the user's comfort
• Textured bottom surface.
• Equipped with an overflow assembly, permitting the user to enjoy a deep soak without worrying about spillage
• ADA compliant - complies with the standards set forth by the Americans with Disabilities Act

Product Technologies / Benefits:

• • Material - ExoCrylic: Kohler baths constructed of ExoCrylic material are 30% lighter than standard tubs, produce 90% fewer volatile organic compounds (VOCs) during manufacturing, and offer an easier, mortarless installation.

Product Specifications:

• Overall Height: 19" (measured from rim to bottom of tub)
• Overall Width: 32" (measured from back outer rim to front outer rim)
• Overall Length: 66" (measured from left outer rim to right outer rim)
• Basin Width (Bottom): 19-5/8" (back to front measurement at bottom of basin walls)
• Basin Length (Bottom): 50-3/8" (right to left measurement at top of basin walls)
• Basin Width (Top): 24-1/16" (back to front measurement at top of basin walls)
• Basin Length (Top): 57-5/16" (right to left measurement at top of basin walls)
• Water Depth: 15-5/16" (depth of water at tub's maximum capacity)
• Maximum Water Capacity: 66 gallons
• Drain Location: Left

Variations of K-1948-LA:

• K-1948-LAW: soaking bath and bask heated surface version of this tub
• K-1949-GLA: bubblemassage air bath version of this tub
• K-1949-GLAW: bubblemassage air bath and bask heated surface version of this tub
• K-1949-VBLA: vibracoustic version of this tub
• K-1949-VBLAW: vibracoustic and bask heated surface version of this tub
• K-1949-LA: whirlpool version of this tub
• K-1949-HLA: whirlpool and heater version of this tub
• K-1949-LAW: whirlpool and bask heated surface version of this tub
• K-1949-XHGLA: whirlpool and bubblemassage air bath version of this tub
